Mini Air Cylinder Stainless Steel Piston Rod Pneumatic Reciprocating Motion Equipment 20mm BoreMI20x225

Item Type: Mini Air Cylinder
Material: Stainless steel
Inner Diameter: Approx. 20mm / 0.8in
Action Type: Reciprocating linear motion
Working Medium: Air
Operating Pressure Range: 0.15-1.0MPa (22-145psi)
Guaranteed Pressure Resistance: 1.5MPA (215psi)
Operating Speed Range: 30-800mm/s
Connecting Caliber: M5 x 0.8
Purpose: Use compressed air as power to drive the mechanism for linear, swing and rotation motions
Applicable Scenarios: Manipulators, take out arms, feeding equipment, screen printing machines, pad printing machines, conveying equipment, transportation machinery, electronic machinery laboratories, teaching equipment, machine tools, food packaging machinery, rubber and rubber machines, automobile manufacturing, Woodworking, construction machinery, aviation transportation industry, national defense and military equipment, health equipment, environmental protection equipment, etc.

Features

1、The mini air cylinder uses compressed air as power to drive the mechanism for linear, swing and rotation motions.
2、The cylinder adopts excellent sealing ring, which can effectively prevent the piston from leaking and improve the sealing performance.
3、Made of stainless steel, has high strength and corrosion resistance, not easy to deform after long term use.
4、The bore of the air cylinder is 20mm, the size is standard, and the installation and connection are tight.
5、Commonly used in manipulators, conveying equipment, food packaging machinery, automobile manufacturing, woodworking, etc.

Package List

1 x Mini Air Cylinder
