Product Overview
Product Material: PPO plastic, copper tin plating
Gross Weight: 154g / 5.4oz
Rated Current: 50A
Flame Rating: UL94 VO
Safety Level: II
Pullout Force: ≥ 50N
Insertion Force: ≤ 50N
Connection System: Crimping connection
Temperature Range: - 40 ℃-+90 ℃
Features
1、Widely Compatible: The MCH40 solar photovoltaic connector is compatible with all standard connectors, is usually used for solar panel DC output, solar panel output connection extension, and solar panel output convergence.
2、PPO and Copper Tin Plating: This connector uses PPO as the shell and copper tin plating as the conductor. It is dustproof, waterproof, strong anti aging, anti UV, and has a long service life.
3、Stable Self Locking Structure: The solar panel cable connector adopts crimping connection system, and the male and female heads are equipped with self locking structure, which can be opened and closed freely.
4、IP67 Waterproof: High strength waterproof ring is designed in th solar connector, and the waterproof level of the plug in box is IP67.
5、Quick Installation: Plugs can be installed and removed quickly and easily without any additional instruments. The solar photovoltaic connector is durable and practical.
Package List
1 x Male Solar Connector
1 x Female Solar Connector
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.9 Inch |
| Height | 1.56 Inch |
| Length | 4.68 Inch |
