10KV Above Ground Insulation Piercing Connector High Low Voltage Cable Splice Connector Grounding Clamp JBC10‑6

Item Type: Insulation Piercing Connector
Model: JBC10-6
Material: PVC, Copper
Voltage Level: 10KV
Main Line: 50-240mm²
Branch Line: 35-150mm²

Features

1、Product Usage: This insulated piercing connector can eliminate power outages and can be applied for overhead services such as street lighting, ensuring reliable connections without hotspots, loose connections, or damaged wires.
2、Non Wire Stripping: The main line specification is 50‑240mm², the branch line is 35‑150mm². When using this connector, there is no need to peel off the cable insulation and stage main cable to make cable branches.
3、Copper Piercing Piece: The piercing piece is made of all copper material, and the finish is tin plated to ensure excellent conductivity. It is not easy to corrode or oxidize and is suitable for copper aluminum wires.
4、Insulated Shell: This piercing connector adopts an insulated housing, which is hard and flame retardant, not easily corroded, aged or damaged, and has a long service life. You can use it with confidence.
5、Sealing Structure: This insulated piercing connector is suitable for indoor and outdoor use. The interior is filled with insulating thermal oil, and the sealing structure improves insulation and conductivity.
6、Applicable Scenarios: The insulated piercing connector is easy to install, suitable for various power engineering projects, urban power, road lighting, industrial power, bridge lighting, and garden lighting.

Package List

1 x Insulation Piercing Connector
1 x Branch Line Cover
