Product Overview
Item Type: Gear pump
Model: ZC-530
Rated Voltage: 24v
Operating Voltage: DC9V-24V
No Load Rated Current: 0.9A ± 10%
No Load Water Discharge: 4.1Lmin ± 10%
Pressure: 3.0KG ± 10%
Rated Current at 1KG Load: 1.2A ± 10%
Rated Water Discharge Volume at 1KG Load: 2.5L / min ± 10%
Suction Height: 1M
Noise: 58dB within 0.5M
Water Temperature: 0 ℃ ~ 100 ℃
Ambient Humidity: 45% ~ 85%
Power: 12.5W
Performance: Low noise
Speed: 299 (rpm)
Air Cylinder Capacity: 40 (L)
Refueling Capacity: 20.4 (L)
Continuous Use Working Life: 10 hours
Model: ZC-530
Rated Voltage: 24v
Operating Voltage: DC9V-24V
No Load Rated Current: 0.9A ± 10%
No Load Water Discharge: 4.1Lmin ± 10%
Pressure: 3.0KG ± 10%
Rated Current at 1KG Load: 1.2A ± 10%
Rated Water Discharge Volume at 1KG Load: 2.5L / min ± 10%
Suction Height: 1M
Noise: 58dB within 0.5M
Water Temperature: 0 ℃ ~ 100 ℃
Ambient Humidity: 45% ~ 85%
Power: 12.5W
Performance: Low noise
Speed: 299 (rpm)
Air Cylinder Capacity: 40 (L)
Refueling Capacity: 20.4 (L)
Continuous Use Working Life: 10 hours
Features
1、Adopt the structure of deceleration for torsion increasing, such gear pump is driven by brush motor with the characteristics of small volume and high pressure.
2、Ultra quiet, with high water lift and low power consumption, self priming pump can make energy saving and environmental protection.
3、With low starting current in high efficiency, such oil pump can keep stable operation.
4、This self priming pump is made of premium material, which is sturdy with long service life.
5、After many inspections before leaving the factory, the pump can be used with confidence.
Package List
1 x Gear Pump
Package Weight and Dimension
| Weight | 0.81 lb |
| Width | 2.73 Inch |
| Height | 2.34 Inch |
| Length | 4.68 Inch |
