2P Dual Power Automatic Transfer Switch Generator Transfer Changeover Switch AC110V 50Hz 60Hz 63A

Item Type: Double Power Automatic Transfer Switch
Material: PC, Silver
Rated Current Le: 63A
Insulation Voltage Ui: AC690V
Rated Voltage Ue: AC110V
Frequency: 50 60HZ
Rated Control Voltage US: 110VAC 85%Us-110%Us
Grade: PC Grade
Specification: 2P
Life Span:
Electrical: 2000 Times
Mechanical: 5000 Times
Rated Short Circuit Current: 50kA
Fuse: RT16 00 63A
Rated Impulse Withstand Voltage: 8kV
Auxiliary Circuit: Two Relays, Each Relay Has Two Sets Of Contact Capacity AC110V50HZ Le 5y
Touch Time: <50ms
Operation Changeover Time: <50ms
Return Time: <50ms
Closing Time: <50ms

Features

1、2 Operation Methods: Automatic transfer switch can be operated automatically or manually to ensure the continuity of power supply, compact structure and reliable transmission.
2、Continuous Power Supply: The automatic transfer switch operates so that when the normal power supply is abnormal, the standby power supply works immediately to ensure the continuity of power supply. When the normal power supply is on, it will automatically switch back to normal power supply from the backup power supply.
3、Standard 35mm Rail Mount: This automatic transfer switch is suitable for 50 or 60Hz AC rated 110V 63A emergency power supply system, designed for home rail mounting and dedicated for PZ30 distribution box.
4、Flame Retardant PC Material and Silver Contacts: The dual power automatic transfer switch is made of flame retardant PC material, which is well insulated and high temperature resistant, and silver contacts, which are anti aging and easy to install and maintain.
5、Widely Used: The automatic transfer switch is anti interference, self throwing and self repeating type, used in various scenarios where continuous power failure is not allowed, families, shopping centers, factories, laboratories, farms, etc.

Package List

1 x Dual Power Automatic Transfer Switch
