Product Overview
Model: GPS-JG-006
Material: ABS + Copper
Uses: GPS, network signal transmission and gain
GPS Frequency: L1 1575.042mhz±1.023mhz
4G Frequency: 698-2700mhz
2.4G Frequency: 2400-2500mhz
GPS Gain: 28DBI
WIFI and 4G Gain: 5DBI
Standing Wave Ratio: ≤1.5
Impedance: 50Ω
Maximum Power: 50W
Antenna Interface: SMA male inner pin
Waterproof Grade: IP67
Storage Temperature: -20-40℃
Polarization Method: Vertical Polarization
Line Type: RG174
Applicable Equipment: 4G full band module, Bluetooth module, GPS navigation module, such as number picker, advertising machine, vending machine, car navigation, bus stop announcer, etc.
Features
1、ABS MATERIAL: The antenna is made of excellent ABS material, light weight and wear resistance, easy to install and carry.
2、IP67 PROTECTION: With IP67 waterproof protection, it can easily cope with various rainwater complex environments.
3、LESS INTERFERENCE: Faster independent channel transmission, reducing common channel interference and enhancing signal gain.
4、RG174 COPPER WIRE: Using RG174 high density copper wire, which has wide coverage, small attenuation and good stability.
5、3 IN 1 ANTENNA: 3 in 1 4G WIFI GPS chassis antenna, support 4G full band module, Bluetooth module and GPS navigation module.
6、MULTIPLE USAGES: Used in number pickers, advertising machines, vending machines, car navigation, bus stop announcers, etc.
Package List
1 x Antenna
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 2.34 Inch |
| Height | 1.95 Inch |
| Length | 6.24 Inch |
