Product Overview
Item Type: Digital Display Voltmeter
Material: PCB
Size: Approx. 48 x 30mm / 1.9 x 1.2in
Purpose: DIY Module
Measuring Range: DC 0V-99.9V
Power Supply Range: DC 5-30V (External Power Supply is Required)
Maximum Input: DC 30.0V
Allowable Error: ±1%; When Greater Than or Equal to 10V, The Error is ±0.3V; When Less Than 10V, The Error is ±0.10
Display Mode: Three Digit 0.56in LED Digital tTube
Working Temperature: -10℃~65℃
Material: PCB
Size: Approx. 48 x 30mm / 1.9 x 1.2in
Purpose: DIY Module
Measuring Range: DC 0V-99.9V
Power Supply Range: DC 5-30V (External Power Supply is Required)
Maximum Input: DC 30.0V
Allowable Error: ±1%; When Greater Than or Equal to 10V, The Error is ±0.3V; When Less Than 10V, The Error is ±0.10
Display Mode: Three Digit 0.56in LED Digital tTube
Working Temperature: -10℃~65℃
Features
1、High Accuracy Measurement: Ultra low cost, high accuracy meets most application requirements.
2、Reverse Connection Protection: The power supply has reverse connection protection, and the reverse connection line will not burn.
3、3 Wire DC Digital Display Voltmeter Head: The measuring range is 0V‑99.9V, and the power supply range is DC 5‑30V.
4、High Brightness LED Display: The display devices all use high brightness LED digital tubes, and the display effect is good.
5、High Quality: It is manufactured by fully automatic SMD technology with superb craftsmanship.
Package List
2 x Module
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.12 Inch |
| Height | 1.17 Inch |
| Length | 3.9 Inch |
