Product Overview
Item Type: DC Power Supply
Material: Metal
Specification: 30V/5A
Output Current: 0-5A
Working Conditions: Temperature: 0-40℃, relative humidity: ≤80%RH
Storage Conditions: Temperature: -20-60℃, relative humidity: ≤80%RH
Temperature Range to Ensure Accuracy: 23℃±5℃
#Voltage
Load Regulation Rate: ≤0.1%+5mV
Power Regulation Rate: ≤0.01%+5mV
Set Resolution: 10mV
Setting Accuracy: ≤0.1%±1 Digits
Readback Resolution: 10mV
Readback Accuracy: ≤0.1%±1 Digits
Ripple: 10mVrms
#Current
Load Regulation Rate: ≤0.2%+3mA
Power Regulation Rate: ≤0.2%+3mA
Set Resolution: 1mA
Setting Accuracy: ≤0.2%±3mA
Readback Resolution: 1mA
Readback Accuracy: ≤0.2%±3digits
Ripple: 8mVrms
OVP: Vmax+2V
OCP: Cmax+1A
Maximum Current: Cmax±0.2%
Working Conditions: Temperature: 0 - 40 ℃, Relative Humidity: ≤80% RH
Storage Conditions: Temperature: -20-60℃, Relative Humidity: ≤80% RH
Cooling Method: Wind Cooling
Weight(Approx.): 1928g/68oz
Size(Approx.): 80 x 150 x 230mm/3.1 x 5.9 x 9.1in
How to Use:
2. The power supply must be grounded when in use.
3. Please pay attention to good ventilation when using. Keep a gap of 10cm with other items on the four sides of the power supply. Do not expose the power supply to dust, corrosive gas and other harmful substances.
4. The power supply specifications should be measured after 15 minutes of "warm-up".
Maintain:
4. If the fault is serious and cannot be solved, please contact your dealer or our company.
Material: Metal
Specification: 30V/5A
Output Current: 0-5A
Working Conditions: Temperature: 0-40℃, relative humidity: ≤80%RH
Storage Conditions: Temperature: -20-60℃, relative humidity: ≤80%RH
Temperature Range to Ensure Accuracy: 23℃±5℃
#Voltage
Load Regulation Rate: ≤0.1%+5mV
Power Regulation Rate: ≤0.01%+5mV
Set Resolution: 10mV
Setting Accuracy: ≤0.1%±1 Digits
Readback Resolution: 10mV
Readback Accuracy: ≤0.1%±1 Digits
Ripple: 10mVrms
#Current
Load Regulation Rate: ≤0.2%+3mA
Power Regulation Rate: ≤0.2%+3mA
Set Resolution: 1mA
Setting Accuracy: ≤0.2%±3mA
Readback Resolution: 1mA
Readback Accuracy: ≤0.2%±3digits
Ripple: 8mVrms
OVP: Vmax+2V
OCP: Cmax+1A
Maximum Current: Cmax±0.2%
Working Conditions: Temperature: 0 - 40 ℃, Relative Humidity: ≤80% RH
Storage Conditions: Temperature: -20-60℃, Relative Humidity: ≤80% RH
Cooling Method: Wind Cooling
Weight(Approx.): 1928g/68oz
Size(Approx.): 80 x 150 x 230mm/3.1 x 5.9 x 9.1in
How to Use:
2. The power supply must be grounded when in use.
3. Please pay attention to good ventilation when using. Keep a gap of 10cm with other items on the four sides of the power supply. Do not expose the power supply to dust, corrosive gas and other harmful substances.
4. The power supply specifications should be measured after 15 minutes of "warm-up".
Maintain:
4. If the fault is serious and cannot be solved, please contact your dealer or our company.
Features
1、Regulated DC power supply, suitable for manufacturing industry, colleges and universities and household appliances maintenance.
2、With LED display of OVP, OCP, four‑digit voltage and current, clear and intuitive, convenient for using.
3、Features 0‑30V output voltage and 0‑5A output current, which has stable and reliable performance.
4、Made of high quality metal material, rugged, anti‑corrosion and durable, which has long lifespan.
5、Manufactured according to the original production specifications, in line with strict quality standards.
Package List
1 x DC Power Supply
1 x Power Cord
1 x 2-In-1 Test Line
1 x Manual
Package Weight and Dimension
| Weight | 4.24 lb |
| Width | 8.58 Inch |
| Height | 5.85 Inch |
| Length | 11.7 Inch |
