360°Low Voltage Microwave Radar Sensor Light Motion Movement Detector Switch DC 12-24V

Condition: 100% Brand New
Item Type: Microwave Sensor Switch
Material: ABS
Diameter: Approx. 9.5cm / 3.7in
Height: Approx. 4.2cm / 1.7in
Output Type: Relay node (switch) signal
Installation: Indoor, ceiling installation
HF System: 5.8Hz+/-75MHz CW Radar
Power Consumption: <0.5W
Transmission Power: <0.2mW
Load Current: 7A (Maximum)
Detection Angle: 360°
Working Delay: 10s-5min
Detection Distance: 2-10m / 6.5-32.8ft
Light Control Illumination: 10-2000LX
Working Temperature: -35℃~80℃
Weight: Approx. 127g / 4.5oz

Features

1、It uses microwave sensors, which has better performance and safer than infrared sensors.
2、Use microwave radar as control signal source to detect human movement. When someone enters the detection area, the indicator lamp will immediate light.
3、The detection range is 360°, which is easy to install and provides high detection probability.
4、Perfect for closets, basements, laundry, garages, bathrooms, aisles and stairs.
5、High sensitivity, long induction distance, strong reliability, large induction angle, wide range of power supply voltage.
