4-20mV to 0-5V 0-10V Converter Module DIY Linear Conversion Transmitter Sensor Module

Item Type: Voltage Converter Module
Material: PCB
Input Current: (4.00MA ~ 20.00MA/0.00mA ~ 20.00mA)
Control Mode: 4.00MA (milliampere) ~ 20.00MA (milliampere) input is converted to corresponding (0.00V ~ 5.00V/0.00V ~ 10.00V).
Output Method:
J1 pad on the circuit board: open circuit (input 4.00mA, ~ 20.00mA); short circuit (input 0.00mA ~ 20.00mA), the default is open circuit
The J2 pad on the circuit board: open circuit (output 0.00V ~ 5.00V); short circuit (output 0.00V ~ 10.00V), the default is open circuit.
Module Interface:
24V: Power supply positive port (9V ~ 24V).
G: Power ground interface.
IN: Signal input interface (4.00MA ~ 20.00MA/0.00MA ~ 20.00MA).
G: Power ground interface.
OUT: Signal output interface (0.00V ~ 5.00V/0.00V ~ 10.00V).
G: Power ground interface.

Features

1、Suitable for remote data acquisition and control equipment.
2、Silver alloy contacts have good conductivity and quick response.
3、Compact appearance, convenient installation and simple use.
4、The voltage can be converted from 4‑20mV to 0‑5V 0‑10V, with good performance.
5、High efficiency, very reliable and practical, suitable for various electronic projects.
