4P Automatic Transfer Switch 35mm Rail Mount Dual Power Generator Changeover Switch AC400V 125A

Item Type: Automatic Transfer Switch
Material: PC, Silver
Rated Current Le: 125A
Frequency: 50/60HZ
Level: PC Level
Specification: 4P
Service Life: Electrical: 2000 Times; Mechanical: 5000 times
Rated Short Circuit Current: 50kA
Fuse: RT16-00-63A
Auxiliary Circuit: 2 relays, each with 2 sets of contact capacity, AC220V50HZ le=5y
Touch Time: <50ms
Operation Switching Time: <50ms
Return Time: <50ms
Closing Time: <50ms

Features

1、MAIN PURPOSE: A miniature household power switch, mainly used to test whether the main power supply or standby power supply is normal to ensure power continuity, reliability and security.
2、OPERATION METHOD: The dual power switch supports manual and automatic operation, millisecond switching without power failure, reliable transmission, easy installation and maintenance.
3、35MM RAIL MOUNT: The automatic transfer switch adopts 35mm standard guide rail installation method, suitable for PZ30 distribution boxes, with a compact structure, and takes less space.
4、DURABLE MATERIAL: The switch shell is made of PC flame retardant plastic, with good insulation, high temperature and aging resistance, the silver contacts greatly improve electrical conductivity.
5、APPLICABLE SCENE: Switch to standby power when power failure occurs, and switch to main power when power failure occurs, widely used in places where continuous power failure is not allowed.

Package List

1 x Automatic Transfer Switch

1 x User Manual
