Product Overview
Item Type: Fuel Hose Kit
Material: Aluminum Alloy + Nylon + Rubber + Stainless Steel
Color: Black
Hose Size: -6 AN
Equivalent Tube Size(Nominal OD): Approx. 3/8in
Hose ID: Approx. 0.34in/8.73mm
Hose OD: Approx. 0.56in/14.22mm
Maximum Operating Pressure: 500 PSI
Burst Pressure Min: 2000 PSI
Working Temperature: -40 ℉- +350 ℉
Package Includes:
4 PCS AN-10 Straight Reusable Swivel Hose End
2 PCS AN-10 45 Degree Reusable Swivel Hose End
2 PCS AN-10 90 Degree Reusable Swivel Hose End
2 PCS AN-10 180 Degree Reusable Swivel Hose End
1 PC 5 Meters/16.4ft AN-6 Nylon Braided Hose
Application: Universal
Material: Aluminum Alloy + Nylon + Rubber + Stainless Steel
Color: Black
Hose Size: -6 AN
Equivalent Tube Size(Nominal OD): Approx. 3/8in
Hose ID: Approx. 0.34in/8.73mm
Hose OD: Approx. 0.56in/14.22mm
Maximum Operating Pressure: 500 PSI
Burst Pressure Min: 2000 PSI
Working Temperature: -40 ℉- +350 ℉
Package Includes:
4 PCS AN-10 Straight Reusable Swivel Hose End
2 PCS AN-10 45 Degree Reusable Swivel Hose End
2 PCS AN-10 90 Degree Reusable Swivel Hose End
2 PCS AN-10 180 Degree Reusable Swivel Hose End
1 PC 5 Meters/16.4ft AN-6 Nylon Braided Hose
Application: Universal
Features
1、Synthetic nitrile inner tube with local stainless steel braid, high strength, not burst, deformation, leakage prevention effect is good.
2、Covered with high quality woven nylon to enhance flexibility and give a cool racing appearance, flexible and heat‑resistant (up to 150 degrees celcius).
3、Suitable for handling any fuel (including ethanol and nitromethane), oil, or coolant. Easy to install.
4、Accurately machine parts to minimize tolerances, provides trouble‑free performance.
5、360 degree adjustable aluminium retention pins, unique taper design, provides a positive grip on the hose to eliminate leakage or separation.
Package List
10 x Oil Hose End
5 x Sealing Ring
1 x Oil Hose
Package Weight and Dimension
| Weight | 3.04 lb |
| Width | 9.36 Inch |
| Height | 4.29 Inch |
| Length | 11.31 Inch |
