Product Overview
Condition: 100% Brand New
Item Type: PWM Dimmer Controller
Material: Plastic
High Brightness 6-25V 900mA LED Driver with 5000:1: dimming
Output Current: 20-900MA; By changing RCS resistance, the maximum current can reach 1200MA.
Maximum Output Power: 20W
Current Adjustment: 1 through the handle, 2 through the PWM control
Frequency Brightness Control Up to 1MHz Switching Speed
Typical Output Current Accuracy 5%
Inherent Open LED Protection
High Efficiency (Up to 97%)
High-End Current Detection
Hysteresis Control: No Compensation
Adjustable Constant Current LED
Item Type: PWM Dimmer Controller
Material: Plastic
High Brightness 6-25V 900mA LED Driver with 5000:1: dimming
Output Current: 20-900MA; By changing RCS resistance, the maximum current can reach 1200MA.
Maximum Output Power: 20W
Current Adjustment: 1 through the handle, 2 through the PWM control
Frequency Brightness Control Up to 1MHz Switching Speed
Typical Output Current Accuracy 5%
Inherent Open LED Protection
High Efficiency (Up to 97%)
High-End Current Detection
Hysteresis Control: No Compensation
Adjustable Constant Current LED
Features
1、Single pin on/off and brightness control using DC voltage or PWM.
2、Inherent open‑circuit LED protection, typical output current accuracy is 5%.
3、High efficiency (up to 97%), high‑end current detection.
4、Single‑pin on/off and use of DC voltage or PWM, frequency brightness control up to 1MHz switching speed.
5、Output current, 20‑900MA, by changing RCS resistance, the maximum current can reach 1200MA.
Package List
5 x PWM Dimmer Controller
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 2.34 Inch |
| Height | 1.95 Inch |
| Length | 3.12 Inch |
