Product Overview
Material: Aluminum Alloy
Weight: Approx. 98g/3.5oz
Continuous Current: 80A
Instantaneous Current: 100A
Support Lithium Battery Section: 5 to 12S
Features
1、High Performance MCU: This ESC features a powerful ARM 32 bit cortex core MCU, with a high working frequency of up to 64MHz, delivering a 25% improvement compared to the previous generation MCU.
2、Superior Design: The control and power components of our ESC feature an independent PCB design, ensuring optimal wire routing and component layout. This results in ultra fast response speed and exceptional performance.
3、Multiple Protections: Our ESC provides various protections, including temperature protection, low voltage protection, stall protection, low RPM power protection, and current protection. These customizable settings cater to the needs of different scenarios, ensuring safety and reliability.
4、Versatile Signal Support: Our ESC supports conventional PWM throttle mode with pulse width input, as well as all for DShot and for Proshot digital signals. This versatility allows for compatibility with various flight controllers and enhances overall performance.
5、Aluminum Alloy Construction: Crafted with premium aluminum alloy housing, this ESC effectively dissipates heat and maintains low temperatures, ensuring long lasting durability.
Package List
1 x ESC
3 x Heat Shrink Tubes
3 x Capacitors
1 x Connecting Wire
1 x Accessory
1 x Plastic Box
1 x User Manual
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.12 Inch |
| Height | 1.95 Inch |
| Length | 3.12 Inch |
