Product Overview
Item Type: ATX Power Board
Material: Copper Clad Laminate
Product Size: Approx. 128 x 48.2mm / 5.0 x 1.9in
Model: XH-M229
Pin Number: 24 Pins
Compatible Port: ATX (compatible with some BTX types)
Switch: Yes
Number of Output Groups: 4 Groups of Different Voltages (one -12v, One +12v, One 5v, One 3.3v output terminal)
Material: Copper Clad Laminate
Product Size: Approx. 128 x 48.2mm / 5.0 x 1.9in
Model: XH-M229
Pin Number: 24 Pins
Compatible Port: ATX (compatible with some BTX types)
Switch: Yes
Number of Output Groups: 4 Groups of Different Voltages (one -12v, One +12v, One 5v, One 3.3v output terminal)
Features
1、With output protection fuse, 4 groups correspond to 4 outputs, you can use it with confidence
2、4 groups of different voltages: one -12V, one +12V, one 5V, one 3.3V output terminal, the output terminal can pass large current
3、Each output has a 5A fuse. In case of overcurrent, the fuse can be replaced, which is very convenient to use
4、Mainly made of copper clad laminate material, with 24 pins, also compatible with some BTX types
5、The power switch is ideal for easy control and is designed to use your power supply to create a desktop power supply with four channel voltage
Package List
1 x ATX Power Board
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.12 Inch |
| Height | 1.95 Inch |
| Length | 5.07 Inch |
