Product Overview
Rated Current: 32A
Product Function: Short circuit, overload protection
Installation Mode: Guide rail installation
Product Pole: 2P
Frequency: 50hz
Breaking Capacity: 4500A
Features
1、SAFE FLAME RETARDANT: Interlock circuit breaker provide safe insulation, overall flame retardant, strong adaptability to environment, to meet the needs of various applications, but also reliable operation in harsh environment
2、CLEAR DISPLAY: Interlock isolator switch with visual indicator window, on and off at a glance, avoid misoperation
3、RAIL INSTALLATION: Interlock circuit breaker with tight buckle, firmly stuck rail, can also use screws fixed installation
4、A VARIETY OF PROTECTION: Protection air switch has the features of safety protection, short circuit protection, overload protection and high breaking capacity
5、TECHNICAL PARAMETERS: Protection air switch rated current for 32A, rated voltage is 400V, 2P product poles, and frequency for 50hz
Package List
1 x Interlock Circuit Breaker
Package Weight and Dimension
| Weight | 0.76 lb |
| Width | 3.9 Inch |
| Height | 3.51 Inch |
| Length | 3.9 Inch |
