Product Overview
Item Type: Bi-Direction Switch
High Definition Multimedia Interface Version: High definition multimedia interface 2.0 version
HDCP Version: HDCP1.2 version
Supported High Definition Multimedia Interface Resolution: 2160 / 1080P24fs / 1080P / 1080i / 720P / 576P / 576i / 480P / 480i
Supported Video Color Format: 24bit
Supported Audio Format: LPCM7.1 / Dolby-AC3 / DTS / DSD
Data Transmission Speed: 5.1Gbps
Input Video Signal: 5.0V p-p
Frequency Bandwidth: Up to 225MHz
Support Output Line: 25mAWG24 or 20mAWG26
Working Temperature: -15℃~+55℃
High Definition Multimedia Interface Version: High definition multimedia interface 2.0 version
HDCP Version: HDCP1.2 version
Supported High Definition Multimedia Interface Resolution: 2160 / 1080P24fs / 1080P / 1080i / 720P / 576P / 576i / 480P / 480i
Supported Video Color Format: 24bit
Supported Audio Format: LPCM7.1 / Dolby-AC3 / DTS / DSD
Data Transmission Speed: 5.1Gbps
Input Video Signal: 5.0V p-p
Frequency Bandwidth: Up to 225MHz
Support Output Line: 25mAWG24 or 20mAWG26
Working Temperature: -15℃~+55℃
Features
1、The switch can be used with most devices equipped with standard high definition multimedia interface ports and Compatible with most electronic products.
2、With high resolution, user can watch audio in high definition; using this switch, user can enjoy the most luxurious video and audio.
3、This switch 1 in 2 out or 2 in 1 out can connect two high definition multimedia interface sources to one display, or connect one source to switch between two displays (only one display is displayed).
4、With small in size, light in weight, this bi-direction switch is easy to remove.
5、The switch is easy to install, plug in the high definition multimedia interface cable directly, and then press the button.
Package List
1 x Bi-Direction Switch
1 x User Manual
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.9 Inch |
| Height | 0.78 Inch |
| Length | 4.68 Inch |
