Product Overview
Motor Parameters:
Housing Material: Aluminium Alloy
Size: Approx. 24x40mm / 0.94x1.57in (Without Cable, Shaft)
Colour: Red
Wattage: 400
Maximum. Speed: 50000
Maximum. Amperage: 47A
Shaft Diameter: Approx. 2.3mm/0.09in
Shaft Length: Approx. 12mm/0.47in
Connector: 3.5mm Banana Head
ESC Parameters:
Material: Plastic, Aluminium Alloy
Size: Approx. 40x27x21mm / 1.57x1.06x0.83in (Without Cable)
Colour: Red
Continuous Current: 35A
Peak Current: 120A
Applicable Battery (Without Battery): 2-3 Cells Lipo, 4-9 Cell Nimh
Applicable: For 1/16 1/18 RC Car Universal
Features
1、High Torsion: Brushless motor has a four high torsion rotor design with powerful torsion and stable output power.
2、Fine Crafted: Brushless motor uses CNC processing 6061 T6 aluminum front and rear cover. High purity resistance copper coils, effectively providing high efficiency.
3、High Durability: Brushless motor has high tough stainless steel output shafts and high accuracy bearings to build a motor super durability.
4、Superior Performance: ESC adopts the highest quality component to ensure efficient operation; rich programmable projects, suitable for various RC tires and tracks.
5、Multiple Protection: Brushless ESC has multiple protection functions, low pressure cutting protection, overheating protection and throttle signal loss protection.
6、Universal to Use: Brushless motor ESC kit can easily change the internal sequence and make the electrical use of various motors.
Package List
1 x Motor
1 x ESC
1 x Manual
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 4.68 Inch |
| Height | 1.56 Inch |
| Length | 5.46 Inch |
