Product Overview
Material: PCB
Display Color: Red
Display Mode: Three Digit 0.36 Inch LED Digital Tube
Control Accuracy: 0.1V
Power Consumption: <1.5W
Stop setting ≦11V, ≥ 14V start, ≥ 15V stop:
Features
1、[Digital Display Design] DC6V‑80V lithium ion batteries can be set up battery charge controller board, using three digit 0.36 inch LED digital tube display, the maximum input voltage of DC80V, if the input voltage is higher than 80V may be permanently damaged.
2、[Multi Application] Charger module for all applicable voltage range of electric bike batteries, car battery discharge protection, over discharge protection for various storage batteries. Protection of input voltage of solar energy, solar panels and wind turbines, etc.
3、[Voltage Correction] Input terminal connected to DC 30V (only recognize the voltage of 30V), short circuit the board in the upper right corner of the display of the two welding points (Calibration) for more than 1 second, the digital display CA.L flashing and then stop, release the two short circuit welding points that correction is complete.
4、[Use] Battery over discharge voltage setting, due to the different loads, the cut off voltage required also varies, according to their own measurement in the actual use of the termination voltage value, provided that the cut off voltage shall be greater than the battery over discharge voltage.
5、[Overvoltage Setting Range] 6‑80V unrestricted (display ‑‑‑), the factory default is not limited. Another overvoltage voltage should be greater than the discharge voltage, such as the setting can not be + or ‑, then check the HV key setting value is appropriate.
Package List
1 x Charger Module
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 2.34 Inch |
| Height | 0.78 Inch |
| Length | 3.9 Inch |
