DC 1000V 40KA Surge Protector Arrester Protective Device for Photovoltaic Power System White 3P

Item Type: DC Surge Protector
Model: SGSP 40
Uc: 1000VDC
In: 20KA(8/20μs)
Inmax: 40KA(8/20μs)
Up: ≤3.8KV
Shell Material: Fireproof and high flame retardant PC
Installation: 35 standard guide rail
Protection Grade: IP20

Features

1、CIRCUIT PROTECTION: DC surge protector with built in overcurrent, overheating, temperature control and short circuit protection to ensure safe operation.
2、EASY INSTALLATION: The surge protector is a module design, adopts 35mm standard guide rails mounting, which is easy to install and replace.
3、GOOD PERFORMANCE: With IP20 protection level, the surge protective device has small leakage current, quick response and low residual voltage.
4、VISIBLE WINDOW: The color of the viewing window indicates the working state of the protector, clear and intuitive, with gap discharge electrode.
5、PC MATERIAL: The shell of the protector is made of PC material, which is fireproof and flame retardant, stable and reliable, ensuring safe use.

Package List

1 x Surge Protector
