DC Buck Boost Converter Adjustable Voltage CC CV Power Supply Module 7‑32V 4A 50W

Item Type: DC Buck Boost Converter
Input Voltage: 7V-32V
Output Voltage: 0.5V-32V (less than 1.8V is weak output capacity)
Output Current: Enhanced heat dissipation up to 4A
Output Power: Enhanced heat dissipation 50W
Voltage Resolution: 0.01V
Current Resolution: 0.001A

Features

1、VOLTAGE AND CURRENT: Converter input voltage range DC 7V‑32V, output voltage DC 0.5V‑32V; Maximum output current 5A, recommended to use less than 4.5A; Maximum output power 75W, recommended to use within 50W
2、HIGH ACCURACY: The buck converter consists of a 36u thickened circuit board, a high Q inductor with an output LED indicator, and a excellent solid state capacitor that can effectively filter out high frequency noise. Suitable for all kinds of electronic projects
3、HIGH SECURITY: Buck boost converter built in security chip to prevent input backconnection; The output is prevent backflow, so that not necessary to add prevent backflow diode when charging the battery
4、SWITCH TIMER: Buck boost converter module switch support timing, full automation, hands free, make work easier and faster
5、HIGH EFFICIENCY HEAT DISSIPATION: Buck boost voltage converter with cooling fan, can automatically adjust according to the working temperature, prevent circuit overheating

Package List

1 x Module

1 x Small Fan

4 x Screw

4 x Nut
