DC Circuit Breaker 2P DZ47Z 125 100A DIN Rail Miniature Circuit Breaker for Solar PV System 1000V Red

Item Type: DC Circuit Breaker
Material: Pa66
Rated Current: 100A
Rated Voltage: DC 1000V
Rated Limit Short Circuit Breaking Capacity (Industrial Icn): 10KA
Use: Solar energy Photovoltaic special electric motorcycle, electric car special
Mechanical Life: 20000 times
Applicable Temperature: -35℃-70℃

Features

1、[Ensure Safety] Circuit breakers can be used to ensure low voltage electrical systems from overcurrent damage caused by overloads or short circuits.
2、[Sensitive Response] The electromagnetic decoupling system can decouple immediately when the circuit is short circuited to ensure the safety of the circuit.
3、[10KA Breaking Capacity] The rated ultimate short circuit breaking capacity of our circuit breakers is 10KA, which is very suitable for home use.
4、[DIN Guide Rail Installation] The circuit breakers are modular in construction with screw clamp wires and can be installed via 35mm DIN rails.
5、[Pa66 Housing] Our circuit breaker is made of nylon material Pa66, which has excellent flame retardant safety performance.

Package List

1 x DC Circuit Breaker
