Product Overview

Features:
1. Adopted of high quality electronic components, and precision process, ensure for the durability
2. Stable performance and high efficiency conversion rate.
3. Small body and it can provide excellent performance
4. Available in six styles for your choice
5. Suitable for ADC / DAC / operational amplifier, RS232 RS485 RS422 bus, audio equipment, LCD power supply, instrumentation equipment, MCU board, motor power, instrument multimeter, Wifi / router / Ethernet equipment

Specification:
Condition: 100% Brand New
±5V:
Maximum Input Current 2A
Maximum Output Current: + Vo Is 1A, -Vo Is 200mA
±6V:
Maximum Input Current 2A
Maximum Output Current: + Vo Is 1A, -Vo Is 200mA
±9V:
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 800mA, -Vo Is 180mA
±12V:
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 700mA, -Vo Is 150mA
±15V:
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 600mA, -Vo Is 120mA
±24V:
Maximum Input Current 1.8A
Maximum Output Current: + Vo Is 400mA, -Vo Is 100mA
Operating temperature Range : -40~+125℃
Storage temperature Range : -65~+150℃
Weigh: Approx. 4g / 0.1oz
Size: Approx. 25 * 16.3 * 6.6mm / 1.0 * 0.6 * 0.3in

Package List:
1 * Step up Power Supply

Note:
2. Output power can not be greater than the maximum load for a long time
3. Input power must be greater than the output power, because the power consumption of the module itself

Features

1、Adopted of high quality electronic components, and precision process, ensure for the durability
2、Stable performance and high efficiency conversion rate.
3、Small body and it can provide excellent performance
4、Available in six styles for your choice
5、Suitable for ADC / DAC / operational amplifier, RS232 RS485 RS422 bus, audio equipment, LCD power supply, instrumentation equipment, MCU board, motor power, instrument multimeter, Wifi / router / Ethernet equipment
