Product Overview
Material: ABS
Bandwidth: DC-10MHz
Rise Time: ≤7.5ns
Time Base: 25ns/div~25ms/div, 1~2~2.5 Step
Maximum Real Time Sampling: 100MS/s
Display: 4.3 Inch True Color LCD Screen, 65 Colors, 800x480 Pixels
Channel: 1 Channel
Maximum Storage Depth: 64KB
Time Base Accuracy: ±100ppm
Input Coupling: DC, AC, GND
Input Impedance: 1MΩ±2%, 20pF±5pF in Parallel
DC Gain Accuracy: ±3%
Vertical Sensitivity: X1: 20mV/div~20V/div, X10: 200mV/div~200V/div
Triggering Type: Edge Triggering
Triggering Mode: Auto, Normal
Auto Measurement: Period, Frequency
Features
1、[High Performance] The digital student oscilloscope adopts advanced digital technology for high performance and accuracy, capable of precisely capturing and displaying signal waveforms.
2、[Multi Functional] The oscilloscope offers various measurement functions and display modes, such as auto measurement, spectrum analysis, waveform storage, and playback, catering to diverse experimental needs.
3、[Real Time Data Acquisition] The digital oscilloscope supports real time data acquisition and analysis, fast sampling, and high speed waveform display to aid students in better understanding the workings of electronic circuits.
4、[Software Support] Equipped with dedicated software, the oscilloscope can perform data analysis, export, and storage. Some models also support firmware upgrades to maintain updated device performance and functions.
5、[Compact and User Friendly] This lightweight digital oscilloscope is easy to carry, with user friendly design, perfectly suitable for student use in laboratories and classrooms.
Package List
1 x Digital Oscilloscope
1 x Power Cord
1 x Test Cable
1 x User Manual
Package Weight and Dimension
| Weight | 2.04 lb |
| Width | 6.63 Inch |
| Height | 5.07 Inch |
| Length | 12.09 Inch |
