Product Overview
Material: Stainless Steel + Aluminum Alloy
Uses: Industrial
Battery: 3V CR2032 x 2 Button Battery (without Battery)
Scale Unit: Metric Scale, Imperial Scale
ABS Key: Relative Measurement Absolute Measurement Conversion
SET Key: In the inch measurement state, each time you press this key, the resolution of the fractional part will switch between 1/3, 1/64, and 1/128
Mm In Key: Metric Inch Conversion at Any Position
ON OFF Key: Power Switch Key
ZERO Button: Reset Button at Any Position
Response Speed Of Moving Grid Sensor: 3 Meters/S
Features
1、Basic Specifications: The multi function digital display ruler series is equipped with a display screen, which can be used for both horizontal and vertical purposes, with high accuracy and a resolution of 0.01mm.
2、Optimized Design: The moving grid module displacement sensor adopts optimized design, has strong anti interference ability, no over speed error occurs, and the response speed is 3 meters/s.
3、Hole Installation: Digital display ruler with installation hole design, back installation hole, suitable for use with various equipment and machine tools.
4、Strong Magnetic Force: The back of the display screen of the digital display ruler has strong magnetic force, which can be adsorbed on iron objects.
5、Measurement at Any Position: The external digital display ruler can be used for fixed measurement at any position, which is very convenient to use.
Package List
1 x Digital Display Ruler
1 x Base
3 x Bracket
2 x Screw
1 x User Manual
Package Weight and Dimension
| Weight | 0.7 lb |
| Width | 2.73 Inch |
| Height | 1.56 Inch |
| Length | 13.65 Inch |
