DM100 Multimeter Digital High precision Intelligent AC/DC Voltage Current Frequency Tester

Features:
Specifications:
Condition:100% Brand New
Color: As shown in the picture
Model
Range
Resolution
Accuracy range
DC V
0~999.9mV/9.999V/99.99V/999.9V
0.1mV/1mV/10mV/100mV
±（1.2%+3）
AC V
0~999.9mV/9.999V/99.99V/750V
0.1mV/1mV/10mV/100mV
±（1.5%+3）
DC A
0~999.9mA/99.99mA/600mA/10.00A
0.1mA/0.01mA/0.1mA/10mA
±（1.0%+3）
AC A
0~99.99mA/600mA/10.00A
0.01mA/0.1mA/10mA
±（1.0%+3）
Resistance
0~999.9Ω
0.1Ω
±（0.8%+3）
0~9.999KΩ/99.99KΩ/999.9KΩ
1Ω/10Ω/100Ω
±（0.8%+3）

0~9.999MΩ/99.99MΩ
1KΩ/10KΩ
±（1.2%+5）

Capacitance
0~9.999nF/99.99nF/999.9nF
0.001nF/0.01nF/0.1nF
±（4.0%+5）
0~9.999μF/99.99μF/999.9μF
1nF/10nF/100nF
±（4.0%+5）

0~9.999mF
1μF
±（4.0%+0）

Diode


On-off beep
0~100Ω resistance<15Ω,The built-in buzzer sounds continuously and the green indicator light is on. The measured resistance is between 15Ω and 30Ω, and the buzzer intermittent alarm is green.


characteristic function



display count
10000 count


VA screen back display analog bar + digital dual display


environment temperature
0°C~60°C
0.1°C
±2°C
environment humidity
20-95%
1%
 ±5.0%RH
Battery measurement
0~1.5V（discharging current 40mA）


0~9V（discharging current 20mA)



Buzzer detection
2KHz/2.7KHz/3V（Active or passive small speaker buzzer detection）


true virtual value
1KHz


Ac frequency measurement


High speed sampling
Sampling rate 10 times/second


V.F.C


fuse alarm
600mA/10A FUSE is prompted on the screen after the current protection ratio is fused and a buzzer alarm is given


Insert the wrong alarm
Misplug anti-burn alarm can effectively prevent the instrument from burning out due to the wrong operation of current, and LUSE will be displayed when misplug and buzzer alarm will be given


Data-hold
Yes


Flashlight
Yes


Auto power-off
Automatic shutdown without operation for about 15 minutes


NCV


LIVE
Single-meter pen contact fire line identification


Input impedance
10MΩ


Overload protection


Undervoltage prompt
under 2.4V


General Parameters



Battery measurement
2*DC1.5V AA(Not included)


Security level
CATIII 1000V

Package List:
1*Multimeter (without battery)
2*Test Cable
1*Instruction Manual

Features

1、Intelligent dual core measurement data processing. 10000 count analog bar plus digital double display. High-speed measurement of voltage / resistance / capacitance.
2、Intelligent dual core measurement data processing. 10000 count analog bar plus digital double display. High-speed measurement of voltage / resistance / capacitance.
3、VFC variable frequency voltage measurement function. The fuse is disconnected from the automatic alarm function. 1KHz true rms measurement.
4、NCV non-contact detection voltage. Automatic identification of diodes & on-off files. The contact single-table pen recognizes the fire line.
5、AC voltage and current frequency test. Automatic detection of ambient temperature and humidity values. Analog LCR ruler professional capacitance test.
