EC200U C4 P01 Development Board Pocket LTE Cat 1 Bluetooth Telecommunication GNSS Positioning 40PIN GPIO Interface Mainboard for Computer EC200U AU C4 P01

Item Type: EC200U C4 P01 Development Board
Material: PCB
LTE TDD: B38 B40 B41
GSM: B2 B3 B5 B8
GNSS: for GPS, for GLONASS, for BDS, for Galileo, for QZSS
Bluetooth: 4.2 (BR EDR)
Wireless Fidelity Scan: 2.4 GHz 11b (Rx)
LTE FDD: 10 Mbps downlink; 5 Mbps uplink
LTE TDD: 8.96 Mbps downlink; 3.1 Mbps uplink
NB IoT: Not Supported
Cat M: Not Supported
GSM: downlink 85.6 Kbps; uplink 85.6 Kbps
Telecommunication Protocols: TCP, UDP, PPP, NITZ, FILE, MQTT, NTP, HTTP, HTTPS, SSL, FTP, FTPS, CMUX, MMS
SIM Card: Nano SIM and eSIM Dual SIM Single Mode (Not Included)
Indicator Light:
P01: Module Pin 1, Default is EC200A XX PWM0
P05: Module Pin 5, for NET_MODE Indicator
SCK1: SIM1 Detection Indicator, on when SIM1 Card Is Inserted
SCK2: SIM2 Detection Indicator, on when SIM2 Card Is Inserted
PWR: Power Indicator
Key Switch:
PWK: Power On Off Button
RST: Reboot Button
BOOT: Force Download Button
USB ON OFF: USB Detection Switch
Antennae Interface: LTE Main Antennae, Diversity Antennae, Wireless Fidelity Antennae (Scanning Only), Bluetooth Antennae, GNSS Antennae

Features

1、Professional Design: EC200U LTE Cat 1 wireless telecommunication module, multi mode and multi band; onboard 40PIN GPIO interface, compatible with most of the for RPi HAT expansion boards.
2、Protocol Support: Development board supports TCP, UDP, PPP, NITZ, FILE, MQTT, NTP, HTTP, HTTPS, SSL, FTP, FTPS, CMUX, MMS and other protocols.
3、GNSS Positioning, LED Indicator: GNSS positioning (for GPS, for GLONASS, for BDS, for Galileo, for QZSS); 5 LEDs on board for easy checking of module running status.
4、Onboard: Development board with onboard Nano SIM and eSIM slots, dual card single mode; onboard MIPI interface, support MIPI screen, compatible with for RPi peripherals.
5、Camera Interface: Support customized SPI camera, support 0.3MP; provide plug in tools such as for QPYcom, for Thonny IDE, for VSCode, etc., which is convenient for learning and development.

Package List

1 x Development Board
1 x USB Cable
1 x Connecting Cable
1 x Antennae
