Product Overview
Material: Stainless steel, aluminum alloy
Cutting Angle: ≤0.5°
Applicable Bare Fiber Diameter: 125μm
Fiber Cutting Length: 9-16mm (0.25mm), 10-16mm (0.9mm).
Cutting Times: 48000 times
Suitable Operating Temperature: -40-80°C
Features
1、Flat Cutting Face: The angle of the fiber optic cleaver is accurate, the cutting face is flat and the loss is small.
2、Stainless Steel Slide: The fiber optic cleaver has a stainless steel slide, easy to operate, fluent and safe. Let you work more efficiently.
3、Self Scaled: Fiber optic cleaver has 3 in 1 fixture, bare fiber, pigtail, and skin cable can be cut, with its own scale, no length setter required.
4、High Accuracy: The optical fiber cleaver has high accuracy, the number of cutting is 48000 times, and the suitable operating temperature is ‑40 to 80℃.
5、All Round Protection: Our optical fiber splitter has all round protection, which can reduce the damage of the cutting knife.
Package List
1 x Fiber Optic Cleaver
1 x Instruction Manual
1 x Accessory Box
1 x Storage Box
Package Weight and Dimension
| Weight | 0.73 lb |
| Width | 3.51 Inch |
| Height | 3.12 Inch |
| Length | 5.46 Inch |
