G3/4‑G3/4 Thread Water Pump Adjustable Flow Sensor Pressure Automatic Control Switch

Turn on the water
equipment and water will flow in pipeline. Water impulse induction door
to rotates towards the direction of water, and magnetic control device
rotates together, which will trigger the sensing elements when it
reaches a certain position, to switch on the household pipeline boost
pump. When water flow is turned off, induction door drives magnetic
control device to a certain position under the action of the reset
spring, to switch off pump.
Features:
Specification:
Model: HT-200
Overload Current: 1.5A
Connection Thread: G3/4-G3/4
Liquid Pressure: <0.6Mpa
Liquid Temperature: <70℃
Weight: 194g / 6.8oz (approx.)
Package list:
1 * Flow Switch (with gasket)

Features

1、Stable performance; induction chamber, magnetic control chamber and electronic components are designed separately in order to avoid switch failure caused by iron matter in pipeline is magnetic adsorbed.
2、High temperature resistant materials allows the product to be used for both hot(up to 70℃) and cold water.
3、Low water pressure startup; reset spring is made of high quality stainless steel; it can start up pump when water pressure is >0.03KG.
4、The electronic components as control device will not cause spark during work which is quite safe.
5、This product is widely used for low pressure area family, especially important for low water pressure ignition start-up of water heater, automatic water cycle of solar water heater.
