Product Overview
Item Type: GPS Filter Module
Material: PCB
Center Frequency: 1575MHz
Working Bandwidth: 20MHz
Out-of-Band Suppression: >35db
In-Band Fluctuation: <1.0dB
Insertion Loss: 2.7dB (typical value)
Maximum Power: 10dBm (10mW)
Applicable Temperature: -40℃-70℃
Material: PCB
Center Frequency: 1575MHz
Working Bandwidth: 20MHz
Out-of-Band Suppression: >35db
In-Band Fluctuation: <1.0dB
Insertion Loss: 2.7dB (typical value)
Maximum Power: 10dBm (10mW)
Applicable Temperature: -40℃-70℃
Features
1、With smoothly surface, one‑piece molding without burrs, simple to installation.
2、PCB adopts 1.6mm thick double-sided board, which is strong and durable.
3、Adopting the whole process of spraying tin, it has good passing performance of large and small currents.
4、The heat dissipation area of the product is large, and the service life is better improved.
5、Can be used with peace of mind, with strict quality control and quality assurance.
Package List
1 x Filter Module
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.9 Inch |
| Height | 0.39 Inch |
| Length | 5.85 Inch |
