GYM8-C45 Miniature Circuit Breaker 3 Poles 400VAC Bilateral Busbar Wiring Circuit Breaker10A

Item Type:Circuit Breaker
Pole: 3P
Rated Frequency: 50/60Hz
Rated Breaking Capacity: 4500A
Pollution Degree : 2
Thermal Magnetic Release Characteristics: B C D
Electrical Life: 4000
Mechanical Life: 10000
Degree Of Protection: IP20
Set The Reference Temperature Of The Thermal Part: 30 ° C
Ambient Temperature (Daily Average ≤ 35 ° C): -5 ~ +40 ° C
Storage Temperature: -25~+70°C

Features

1、Bilateral busbar wiring capability to accommodate a wider range of uses.
2、Maximum connection capacity 25 mm, wiring torsion 3N.m, suitable for various installation equipment.
3、Wiring is more secure and stable,not easy to loose.The transparent cover is designed to carry labels.
4、GYM8 miniature circuit breaker is mainly used for AC 50Hz/60Hz, double voltage /400V, rated current 1A ~ 63A overload and short circuit protection, and can also be used for non-frequent switching operation under normal conditions.
5、The indicator function is in the contact position.Compliance with IEC/EN60898-1.

Package List

1 x Circuit Breaker
