Product Overview
Material: PCB
Purpose: Speed Control Module
Maximum Power: 2000W
Maximum Current: 25A
Working Temperature: -40℃~125℃
Features
1、Imported Thyristor: The module adopts imported thyristor, the withstand voltage is as high as 1200V. High quality CBB capacitors can withstand 630V DC withstand voltage.
2、Come with Extension Cord: This controller board potentiometer comes with an extension cord, which is more flexible and convenient for assembly in the machine.
3、Effective Protection: The voltage regulator has a peak voltage absorption circuit to effectively protect the high power thyristor, with a long life and more durable.
4、Accuracy Trimming: This is a voltage regulator that can adjust the minimum output voltage through a accuracy trimming potentiometer.
5、Brightness Adjustment: Connecting suitable load equipment can play the role of brightness adjustment, speed adjustment, pressure adjustment, and temperature adjustment.
Package List
1 x Speed Control Module
1 x Rotary Switch
1 x Wire Row
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.12 Inch |
| Height | 1.56 Inch |
| Length | 3.12 Inch |
