Product Overview
Item Type: Input Output Control Module
Product Material: PCB
Product Model: N4DIG08
Working Current: 10-16mA
Jumper Mode: 8 channel input, 8 channel output, 4 input 4 output.
Input Mode: Low level input (default) and high level input (3.3V/5V TTL).
Output Mode: Low level (default) and high level output (5V TTL).
Default Baud Rate: 9600BPS
Product Material: PCB
Product Model: N4DIG08
Working Current: 10-16mA
Jumper Mode: 8 channel input, 8 channel output, 4 input 4 output.
Input Mode: Low level input (default) and high level input (3.3V/5V TTL).
Output Mode: Low level (default) and high level output (5V TTL).
Default Baud Rate: 9600BPS
Features
1、With 8 Channel: Comes with 8 channels, this control module can connect multiple devices at the same time.
2、3 Jumper Modes: Can easily switch among 8 channel inputs, 8 channel outputs, 4 inputs and 4 outputs modes.
3、9600BPS Baud Rate: The default Baud rate is 9600BPS, and the high speed ensures quick and accurate control.
4、Good Durability: Made of 1.6mm thick PCB double sided board, sturdy and durable, has a long service life.
5、Convenient Use: Large heat dissipation area enables fast cooling and stable working, also easy to carry.
Package List
1 x Input Output Control Module
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 1.17 Inch |
| Height | 0.78 Inch |
| Length | 1.95 Inch |
