Product Overview
Material: ABS
Measurement accuracy: 1CM when distance value ≤25CM, Sx4%CM when distance value ≥25CM
Working Voltage: DC3.3-5V
Blind Zone Distance: <2cm
Communication Level: 3.3V (TTL)
Output Response Time: 19-38ms (settable)
Working Cycle: 100
Output Mode: IIC
Temperature Compensation: Built in
Indoor Range: Approx. 2-400cm/0.8-157.5in
Outdoor Range: Approx. 2-200cm/0.8-78.7in (3000LX), 2-90cm/0.8-35.4in (15000LX)
Application: Robot obstacle avoidance, intelligent trash can detection, parking space detection, intelligent home, etc.
Features
1、UPGRADED MODULE: The ranging sensor module has compact size, small blind area, short response time, high installation adaptability, practical and reliable.
2、IP67 GRADE: This distance measuring sensor module is in IP67 protection grade, waterproof, dust and oil resistant, could well adapt to wet and harsh environment.
3、HIGH ACCURACY: The distance sensor module has high measuring accuracy, which is 1cm when distance value is less than 25CM, and Sx4%CM when distance value is more than 25CM.
4、WIDE RANGE: The indoor range of our ranging module is 2 to 400cm and the outdoor range is 2 to 200cm.
5、APPLICABLE SCOPE: This module can be used for robot obstacle avoidance, horizontal ranging, human body sensing, object approaching and exist detection.
Package List
1 x Laser Ranging Sensor
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 1.17 Inch |
| Height | 0.39 Inch |
| Length | 1.17 Inch |
