Product Overview
Item Type: Latching Relay Module
Model: LR12A01
Working Voltage: DC 12V (8-18V)
Working Current: 60mA(only provide current when the state changes)
Standby Current: 20μA(or zero standby power consumption)
Charging Current: AC 250V/10A, DC 30V/10A
Trigger Mode: Low pulse trigger
Module Interface:
1. V: Positive power supply (VCC)
2. G: Negative power supply (GND)
3. R: Reset (relay closed)
4. S: Setting (relay on)
Relay Output:
1. NO: Normally open the relay interface
2. COM: Common interface relay
Model: LR12A01
Working Voltage: DC 12V (8-18V)
Working Current: 60mA(only provide current when the state changes)
Standby Current: 20μA(or zero standby power consumption)
Charging Current: AC 250V/10A, DC 30V/10A
Trigger Mode: Low pulse trigger
Module Interface:
1. V: Positive power supply (VCC)
2. G: Negative power supply (GND)
3. R: Reset (relay closed)
4. S: Setting (relay on)
Relay Output:
1. NO: Normally open the relay interface
2. COM: Common interface relay
Features
1、Time Control Between 0.1s-270h: Time control is adjustable between 0.1 second and 270 hours, which is a wide range
2、Zero Power Hold Switch: Support zero power hold switch, you can select energy saving mode, very practical
3、Bistable Self Locking Trigger: Latching relay module adopt bistable self locking trigger, possess stable performance
4、18 Functions: A total of 18 functions can be selected, the function is compatible with CE030 FRM01 relay module
5、Excellent Performance: Self locking flip flop come with stable structure, excellent performance and long service life
Package List
1 x Latching Relay Module
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 1.56 Inch |
| Height | 1.17 Inch |
| Length | 3.12 Inch |
