Product Overview
Material: PVC, Copper Nickel Plated Metal
Number of Cores: 4
Line Length: Approx. 1m/39.4in
Rated Current: 4A
Conductor Specification: 22AWG
Contact Impedance: ≤5MQ
Standard: IEC61076-2-101
Applicable Temperature: -25℃ to 80℃
Waterproof Grade: IP67
Features
1、M12 Connector Cable: This M12 connector cable features a single end female connector with 4 gold plated pins, A coding, IP67 waterproof rating, 22AWG wire, and a 3.2ft cable length.
2、Easy Connection: The M12 cable female connector offers a fast and convenient connection, plug and play, flexible and convenient, the installation and disassembly does not require tools.
3、Safe and Reliable: The cable is made with premium PVC sheath that is fireproof and flame retardant, provides excellent insulation performance.
4、Stable Data Transmission: Made with full copper nickel plated metal screw sleeve and pure copper gold plated contact points, guaranteeing stability and reliability of data and signals.
5、Wide Applications: The M12 4 pin cable is the optimal choice for connecting sensors, meeting the requirements of sensor devices and actuator devices in automation applications.
Package List
1 x M12 Connector Cable
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 5.85 Inch |
| Height | 0.78 Inch |
| Length | 8.58 Inch |
