Mini Motor Permanent Magnet AC Synchronous Speed Reduction Eccentric Shaft Accessories80rpm/min AC220V

Item Type: Mini Motor
Model: XD-60KTYZ + bracket
Material: Copper
Output Shaft Size: Approx. 7 x 19mm / 0.3 x 0.7in
Protection Level: IP20
Insulation Resistance: After the rated operation of the motor under normal temperature and humidity, when measuring the insulation resistance between the coil and the motor shell with a DC500V resistance meter, it does not exceed 20MΩ
Temperature Rise: When the gearbox or equivalent heat sink is installed, and the rated operation is performed under normal temperature and humidity, it is normal to measure the temperature rise of the coil by the resistance method to 75-80℃.
Insulation Class: E class (130℃)
Operating Environment Temperature: Motor: -10~+40℃ (no icing)
Use Environment Humidity: 85% or less (no condensation)
Whether Support CW and CCW: Yes
Whether Support Speed Regulation: No

Features

1、The micro motor is a permanent magnet AC synchronous motor, which improves the reliability of motor operation.
2、The motor adopts all‑metal gears, small size and large torsion, stable and quiet operation.
3、The copper coil and deceleration resistor are used to enhance the conductivity and increase the motor torsion.
4、Using high-quality magnetic tiles, higher working efficiency and less dynamic loss.
5、Widely used in home or industry, used in various CNC machine tools, machining, electronic manufacturing, etc.

Package List

1 x Mini Motor

1 x Bracket
