Relay Module 2 Way 12V Input Relays Switch Board Shields for Circuit Communicationn

Item Type: Relay Module
Material: Copper Clad Laminate
Input and Output Wiring and Function Description:
Output Part: NC (Normally Closed) COM (Common Pin) NO (Normally Open)
Load: 220V 10A (Recommended Below 220V 6A)
1 is just the closing and opening of a switch, without any voltage output.
2 Only through 485 communication can send commands to control the opening and closing of the relay.
3 By default, NC COM is connected. When 485 sends the opening command, NC and COM are disconnected, and NO is connected to COM.
Input Part: IN1 Connects to Switch or Voltage Signal (3V-30V)
1. The status of the switch can only be read through the computer, and the relay cannot be controlled.
2. IN1 is connected to the switch (no voltage signal): IN connected to VCC is 1, not connected to 0
Baud Rate: 9600 8 NONE 1
Hexadecimal Sending
Hex Receiving
Hardware Resources
1. RS485 Communication Interface
2. TTL Communication Interface
3.2 Road OPTO Isolated Input
4.2 Road OPTO Isolated Output
5. A User Button
6. A User LED Indicator
7. A Power Indicator
8. A STM32F030F4 Microcontroller
9.2 LEDs Indicating the Status of the Relay
10. Power Terminal Interface (12V Power Supply)
How to Use:
Steps:
1. The software sets the communication baud rate
2. Set the address (the device address used for communication, the default address is 01)
Note: Only connect one device, otherwise the address will be set.
Set the address as: 01
00 10 00 00 00 01 02 00 01 6A 00 　 modify to 01
Set the address as: 02
00 10 00 00 00 01 02 00 02 2A 01 is changed to 02
Set the address as: 03
00 10 00 00 00 01 02 00 03 EB C1 is changed to 03
Read address
00 03 00 00 00 01 85 db
return:
00 03 02 00 01 44 44　01 is the address
The meaning of each byte:
[Address 1]
Relay No. 1 is on: 01 05 00 01 01 00 9d 9a
Byte 1: Address
Byte 2: Function?
Byte 3 4: Register address
Byte 5 6: Register data
Byte 7 8: CRC check
[Address 1]
Relay 0 is on: 01 05 00 00 FF 00 8C 3A
Relay 0 is off: 01 05 00 00 00 00 CD CA
Relay No. 1 is on: 01 05 00 01 FF 00 DD FA
Relay No. 1 is off: 01 05 00 01 00 00 9C 0A
Relay No. 2 is on: 01 05 00 02 FF 00 2D FA
Relay No. 2 is off: 01 05 00 02 00 00 6C 0A
Relay No. 3 is on: 01 05 00 03 FF 00 7C 3A
Relay No. 3 is off: 01 05 00 03 00 00 3D CA
Relay No. 4 is on: 01 05 00 04 FF 00 CD FB
Relay No. 4 is off: 01 05 00 04 00 00 8C 0B
Relay No. 5 is on: 01 05 00 05 FF 00 9C 3B
Relay No. 5 is off: 01 05 00 05 00 00 DD CB
Relay No. 6 is on: 01 05 00 06 FF 00 6C 3B
Relay No. 6 is off: 01 05 00 06 00 00 2D CB
Relay No. 7 is on: 01 05 00 07 FF 00 3D FB
Relay No. 7 is off: 01 05 00 07 00 00 7C 0B
Read the status of No. 0 relay: 01 01 00 00 00 01 FD CA
Read the status of No. 1 relay: 01 01 00 01 00 01 AC 0A
Read the status of No. 2 relay: 01 01 00 02 00 01 5C 0A
Read the status of No. 3 relay: 01 01 00 03 00 01 0D CA
Read the status of No. 4 relay: 01 01 00 04 00 01 BC 0B
Read the status of No. 5 relay: 01 01 00 05 00 01 ED CB
Read the status of No. 6 relay: 01 01 00 06 00 01 1D CB
Read the status of No. 7 relay: 01 01 00 07 00 01 4C 0B
Read all relay status: 01 01 00 00 00 08 3D CC
Flash away instructions:
Note: Turn off immediately after opening, 100MS is a unit [1 stands for 100MS]
Address No. 1:
No. 0 relay flashes on: 01 05 02 00 07 00 CE 42 700MS = 7 x 100MS = 700MS
Relay No. 1 flashes on: 01 05 02 01 08 00 9A 72 800MS
Return: same as sending command
Address No. 2:
No. 0 relay flashes on: 02 05 02 00 05 00 CF 11 500MS
Relay No. 1 flashes on: 02 05 02 01 06 00 9E 21 600MS
All off: 01 0F 00 00 00 08 01 00 FE 95
Full light: 01 0F 00 00 00 08 01 FF BE D5
Single flip instruction:
No. 0 relay flip: 01 05 00 00 55 00 F2 9A
No. 1 relay flip: 01 05 00 01 55 00 A3 5A
No. 2 relay flip: 01 05 00 02 55 00 53 5A
No. 3 relay flip: 01 05 00 03 55 00 02 9A
No. 4 relay flip: 01 05 00 04 55 00 B3 5B
No. 5 relay flip: 01 05 00 05 55 00 E2 9B
No. 6 relay flip: 01 05 00 06 55 00 12 9B
No. 7 relay flip: 01 05 00 07 55 00 43 5B
All flip instructions:
01 05 00 00 5A 00 F7 6A

Features

1、This is a 2 channel 12V relay output board module, which is easy to install and can control most electrical appliances and other devices with current.
2、The relay module has strong driving ability, low power consumption, high exactness and stable performance.
3、The relay module of portable design is easy to operate and can communicate with RS485 TTL.
4、The interface design of the relay module is humanized to meet the needs of more trigger applications.
5、The relay module has a wide range of applications and is suitable for operation by college students, engineers, and technicians.

Package List

1 x 2 Way 12V Relay Module
