RF Switch Module SinglePole 6 Throw NonReflective Electronic Component HMC252 DC3 GHz

Item Type: RF Switch Module
Low Insertion Loss (2 GHz): 1.0 dB
Single Positive Power Supply: VDD = +3V to +5V
Integrated 3: 6 TTL decoder
Application:
1. Base station
2. CATV / DBS
3. MMDS and wireless local area network
4. Test equipment
Overview: HMC252AQS24E is a low-cost non-reflective SP6T switch in a 24-pin QSOP package with a wideband operating frequency range from DC to 3.0 GHz. The switch provides single positive bias and true TTL/CMOS compatibility. The switch integrates a 3:6 decoder, only three control lines and a positive bias are needed to select each path. HMC252AQS24E SP6T can replace SP4T and SPDT MMIC switches and multiple configurations of logic drivers

Features

1、This product has a high operating frequency range and a wide range of applications.
2、With small size, easy to carry and store, convenient to use and with good performance.
3、HMC252AQS24E is a low‑cost non‑reflective SP6T switch in a 24‑pin QSOP package with a wideband operating frequency range from DC to 3.0 GHz.
4、The switch provides single positive bias and true TTL/CMOS compatibility. The switch integrates a 3:6 decoder.
5、HMC252AQS24E SP6T can replace SP4T and SPDT MMIC switches and multiple configurations of logic drivers.

Package List

1 x RF Switch Module
