SDA40 Thin Air Cylinder Aluminum Alloy Double Action Pneumatic Components 10/15/20mmSDA40X15

Item Type: Air Cylinder
Model: SDA40
Main Material: Aluminum Alloy
Working Medium: Air
Working Pressure: 0.15-0.8mpa
Guaranteed Pressure Resistance: 1.5MPa（215Psi）
Buffer Form: Fixed Buffer
Mode of Action: Double Action
Buffering Method: Anti-Collision Pad
Stroke: 10/15/20mm
Temperature: 4℉-176℉ (-20℃-80℃)
SDA40X10:
Double Side: Dia. 10
Tooth M8x1.25
Hole: Dia. 6.5
Piston Rod Diameter: 16
Piston Rod Inner Teeth: M8x1.25 Deep 12
Hole Distance: 19
Air Inlet Thread: PT1/8
Total Cylinder Length: 43
Cylinder Length: 36
SDA40X15:
Double Side: Dia. 10
Tooth M8x1.25
Hole: Dia. 6.5
Piston Rod Diameter: 16
Piston Rod Inner Teeth: M8x1.25 Deep 12
Hole Distance: 24
Air Inlet Thread: PT1/8
Total Cylinder Length: 48
Cylinder Length: 41
SDA40X20:
Double Side: Dia. 10
Tooth M8x1.25
Hole: Dia. 6.5
Piston Rod Diameter: 16
Piston Rod Inner Teeth: M8x1.25 Deep 12
Hole Distance: 29
Air Inlet Thread: PT1/8
Total Cylinder Length: 53
Cylinder Length: 46

Features

1、High quality aluminum alloy material can make sure the durability and stability of the product
2、The front and rear covers are screwed to the cylinder tube, which is tight and will not fall off easily.
3、The piston sealing adopts a special-shaped two-way sealing structure, compact appearance and has oil storage function.
4、The front end cover is guided by self-lubricating bearings, which has good lubrication and guiding performance.
5、Adopt double action mode and fixed buffer form, available in three styles for choice

Package List

1 x Air Cylinder
