Servo Stepper Motor Controller Programmable Motion CNC System 4‑Axis Pulse Output WS55H‑3

Item Type: Servo Stepper Motor Controller
Material: Engineering plastic
Display: 3.5in LCD color screen
Resolution: 320x240
Boot Image Format: 24-bit bitmap BMP
Number of Input Ports: 16
Number of Output Ports: 8
Button Life: 50000 Times
System Power Supply: DC 24V
Power Consumption: 10W
Non-Isolated Load: 120W
Isolation Load: 100W
Number of Controllable Axis: 2-4 Axis X, Y, Z, C(2 Axis and above) linkage
Language: Chinese, English
Storage Procedure: 99
Number of Program Lines: 999
Minimum Data Unit: 0.001mm
Maximum Data Size: ±99999.999mm
Maximum Pulse Output Frequency: Single Axis 400KHz
Single Axis Rapid Movement Speed: 24m/min (when the pulse equivalent is 0.001mm)
Four-Axis Rapid Movement Speed: 21m/min (when the pulse equivalent is 0.001mm)
Moving Speed of Arc Motion: 18m/min (when the pulse equivalent is 0.001mm)
Speed Override: 10%-200% Adjustable
Working Temperature: 0-40℃
Environmental Humidity: 0-85%
Product Use: Welding, drilling, dispensing, spraying, feeding, cutting, grinder, instrument lathe and other motion control systems
Optional Style: Biaxial, Triaxial, 4-Axis

Features

1、Servo stepper motor controller possess large LCD screen, clear display and easy operation
2、Small and exquisite size, intelligent integration of internal components, high space utilization
3、Using international standard G code programming method, simple and easy to operate
4、More convenient USB port, lead‑in/lead‑out programs through U disk, boot image/standby picture can be customized
5、Come with 2ms high‑speed interpolation, X, Y, Z, C can do linear circular interpolation
