Product Overview
Condition: 100% Brand New
Item Type: Thin Film Pressure Sensor
Model: SF45-65
Thickness: <0.4mm
Range: 10kg
Response Point: 150g
Durability:> 1 Million Times
Initial Resistance:> 10MQ (No Load)
Response Time: <1ms
Recovery Time: <15ms
Working Temperature: -20℃ - 60℃
Electromagnetic Interference EMl: Not Generated
Electrostatic Discharge ESD: Not Sensitive
Length: Approx. 65mm / 2.6in
Width: Approx. 50mm / 2.0in
Tolerance: Approx. 0.2mm / 0.01in
Sensitive Area Size: Approx. 45x45mm / 1.8x1.8in
Sensor Size: Approx. 50x65mm / 2.0x2.6in
Pin Distance: Approx. 2.54mm / 0.1in
Item Type: Thin Film Pressure Sensor
Model: SF45-65
Thickness: <0.4mm
Range: 10kg
Response Point: 150g
Durability:> 1 Million Times
Initial Resistance:> 10MQ (No Load)
Response Time: <1ms
Recovery Time: <15ms
Working Temperature: -20℃ - 60℃
Electromagnetic Interference EMl: Not Generated
Electrostatic Discharge ESD: Not Sensitive
Length: Approx. 65mm / 2.6in
Width: Approx. 50mm / 2.0in
Tolerance: Approx. 0.2mm / 0.01in
Sensitive Area Size: Approx. 45x45mm / 1.8x1.8in
Sensor Size: Approx. 50x65mm / 2.0x2.6in
Pin Distance: Approx. 2.54mm / 0.1in
Features
1、Flexible thin film pressure sensor is an artificial flexible simulate sensor device for realizing the perception function of human skin.
2、With dual functions of waterproof and pressure sensitive, high sensitivity and quick response.
3、Support different functional requirements, used in automotive electronics, medicine equipment, intelligent robots, intelligent shelves.
4、Small size, light weight, bending resistance, long service life, easy to install.
5、Stable performance, safe and reliable, can sense tiny pressure or tactile signals.
Package List
1 x Thin Film Pressure Sensor
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 3.12 Inch |
| Height | 0.39 Inch |
| Length | 4.68 Inch |
