Signal Isolator DC 1 Input 2 Output Current Voltage Transmitter Rail Mount Conditioner GLG

Item Type: Signal Isolator
Material: ABS
Model: GLG
Channel: 1 in 2 out
PWR (15-, 16+): 24V DC
Input: 0-10V
2-Wire System: (9-, 13+)
3-Wire: (9+, 10-, 13+)
Power Supply: (9+, 10-)
Output:
Channel 1 (1+, 2-): 0-10V
Channel 2 (3+, 4-): 0-10V
Output Current: Load≤500Ω
Accuracy: 0.1% FS
Working Temperature Range: -20-+55℃
Electromagnetic Compatibility: Comply with GB/T 18268 (1EC61326-1)
Applicable Field Equipment: 2-wire, 3-wire transmitter, current source
Product Description:
DC24V power supply, provides isolated power distribution for the transmitter on site, and at the same time isolates and transmits the current signal generated by the transmitter from the site to the control room, PLC, DCS and other input terminal interface current source, 2-wire system, 3-wire system transmitter General purpose; internal use of high-efficiency magnetic isolation technology, isolation between input, output, and power supply, with high accuracy, high linearity, low temperature drift and other characteristics.

Features

1、Conformal coating is used to protect circuit boards and related equipment from environmental erosion.
2、High‑quality ABS material shell, high temperature and impact resistance, can be used for a long time.
3、35mm standard guide rail installation, easy installation and disassembly, and does not occupy space.
4、Realize the isolation of input, output, power supply and shell, strong anti‑interference ability and high reliability.
5、Has excellent insulation, moisture-proof, anti-leakage, anti-vibration, anti-aging, anti-corona performance, etc.

Package List

1 x Signal Isolator
