Single Phase Energy Meter Rail Frequency Power Factor Meters Multifunctional Measuring Instrument AC250‑450V

Item Type: Single Phase Energy Meter
Material: ABS
Model: SDM009-E
Measurement Accuracy: 1%±2 Words
Alternating Current: AC0-100A (Universal)
Current Display Resolution: 0.01A
Power Frequency: 45Hz-65Hz
Power Factor: 0.00-1.00PF
Active Power: Measurement range is 0-45000W
Electricity: The measuring range is 0-99999kwh, the minimum display resolution of 0-999.99kwh is 0.01kwh
1000.0-9999.9kwh minimum display resolution is 0.1kwh
10000.0-99999kwh minimum resolution is 1kwh
Measuring Speed: About 2 Times Per Second
Installation Method: Rail Type

Features

1、Simultaneous Display: The multifunctional measuring instrument measures AC voltage, current, active power, and electricity and displays on the LCD screen.
2、LCD Screen Display: Multifunction measuring instrument with LCD screen display, which is more intuitive and clear at a glance.
3、6 Parameters: Simultaneously displays 6 parameters such as AC voltage, AC current, active power, power factor, frequency, and electric energy on the instrument.
4、Basic Specifications: The current display resolution is 0.01A, the power frequency is 45Hz‑65Hz, and the power factor is 0.00‑1.00PF.
5、Wide Applications: Widely used for home appliances, inverter power supplies, high and low voltage power distribution cabinets, photovoltaic systems, etc.

Package List

1 x Multifunctional Measuring Instrument

1 x English User Manual
