Solar Fuse Holder PV Panel Cable Connector IP68 Waterproof DC 1000V for Protection 30A

Item Type: Solar Fuse Holder
Material: PPO
Withstand Voltage: DC1000V
Contact Resistance: ≤0.35mΩ
Insulation Resistance: ＞ 500MΩ
Ambient Temperature: -40℃ ~ +90℃
Protection Class: IP68
Safety Level: Ⅱ
Insertion Force: ≤50N
Pull Out Force: ≥50N
Flame Retardant Grade: UL94-VO

Features

1、Higher Safety: Only allows the current to pass in one direction, and blocks reverse current to prevent burning out the photovoltaic panels.
2、Reliable Work: Silver plated T2 copper conductor has small resistance for good electrical conductivity, while IP68 waterproof enables wide use.
3、Wide Matching: Designed for DC application, the solar fuse holder with standard size is highly compatible with various PV cable, very useful.
4、Good Material: Made from premium PPO material, the flame retardant PV connector is not easy to break, also very durable for long term using.
5、Easy to Install: Comes with a light weight and a compact size as well, the convenient installation can be quickly finished in several minutes.

Package List

1 x Solar Fuse Holder
