Product Overview

Item Type: Solar Micro Inverter
Material: Aluminum Alloy
AC Output:
Rated AC Frequency: 50 60Hz
Output Frequency Range: 50Hz: 47.5Hz-52.5Hz, 60Hz: 57.5Hz-62.5Hz
Output Power Factor: >0.99
Total Harmonic Transition Rate of Output Current: THD<5%
Efficiency:
Maximum Conversion Efficiency: 95%
MPPT Tracking Efficiency: 99.90%
Night Loss: <700mW
Mechanical Data:
Working Environment Temperature: -40℃ to +65℃
Storage Environment Temperature: -40℃ to +85℃
Maximum Current of AC Cable: 20A
Protection Level: IP65
Cooling Mode: Natural Cooling
Other Features:
Communication Method: WIFI Wireless Communication (Cloud Monitoring)
Isolation Characteristics: High Frequency Transformer Isolation
Comprehensive Grounding: The PE end of the AC cable is the grounding wire of the equipment, and there are no other grounding ports
Model
Photovoltaic Input (DC, PV)
AC Output
Maximum DC Input Current
Rated Output Power
Maximum Output Power
Rated AC Current
1.3A
MaySun350
11.66A
330W
350W
1.43A
MaySun400
13.33A
380W
400W
1.65A
MaySun500
16.66A
480W
500W
2.09A

Features

1、GRID CONNECTED INVERTER: Micro inverter can independently control parallel components to minimize safety hazards. Pure sine wave output ensures stable and pure output voltage, which can adapt to almost all load appliances.
2、MPPT FUNCTION: Micro inverter has two independent MPPTs, which can achieve maximum power point tracking and maximize the overall output power.
3、EFFICIENT WORK: The inverter is equipped with high precise gauge, allowing you to see the working status of various components. Can be operated and monitored through WiFi or mobile APP, greatly improving overall efficiency. IP65 waterproof, safe to work outdoors.
4、SIMPLE INSTALLATION: Standard input port, simple and secure connection. Integrated AC output port, can easily connect more machines to increase system power and connect to the power grid. The micro inverter can be installed directly behind the module or on a bracket for easy maintenance.
5、MULTIPLE PROTECTION: Inverter automatically stops output in case of power grid failure or power outage, and also has overheating, short circuit, overload, voltage, frequency, temperature and current protection, etc., highly safe and reliable.
