Product Overview
Item Type: Solid State Relay (DC Control AC)
Control Voltage: 3-32VDC
Control Current: DC4-12mA
Load Voltage: 24-480VAC
Load Current: 10A/25A/40A/60A/75A/80A/100A/120A(Optional)
On-State Voltage Drop: ≤1.5V
On-State Leakage Current: ≤2mA
Off-State Time: ≤10ms
Insulation Resistance: 500mΩ/500VDC
Ambient Temperature -30℃-+70℃
Placement Method: Bolted
Work Indicator: LED
Weight: Approx. 90g / 3.2oz
Size: Approx. 30 x 44 x 59mm / 1.2 x 1.7 x 2.3in
Control Voltage: 3-32VDC
Control Current: DC4-12mA
Load Voltage: 24-480VAC
Load Current: 10A/25A/40A/60A/75A/80A/100A/120A(Optional)
On-State Voltage Drop: ≤1.5V
On-State Leakage Current: ≤2mA
Off-State Time: ≤10ms
Insulation Resistance: 500mΩ/500VDC
Ambient Temperature -30℃-+70℃
Placement Method: Bolted
Work Indicator: LED
Weight: Approx. 90g / 3.2oz
Size: Approx. 30 x 44 x 59mm / 1.2 x 1.7 x 2.3in
Features
1、Pure aluminum heat sink, fast heat dissipation
2、SCR and optoelectronic components, non-contact switch
3、Easy to install and widely used
4、Widely used in computer peripheral interface equipment, electric furnace heating thermostat equipment, CNC machinery and industrial automation equipment, etc.
5、Used in a large number of occasions requiring explosion-proof, moisture-proof and anti-corrosion in chemical, coal mine, fireworks and firecracker equipment
Package List
1 x Solid State Relay
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 1.95 Inch |
| Height | 1.17 Inch |
| Length | 2.34 Inch |
