Spur Gear 96 Tooth Aluminum Cylindrical Mod 0.8 14mm Center Hole Hardware Tools

Item Type: Spur Gear
Material: Aluminum
Complete removal of anodizing
Tooth: 96
MOD: 0.8
Pressure Angle: 20 Degrees
Center Hole: Approx. 14mm / 0.6in

Features

1、End thickness is processed to 3mm, which can conceal the screw head, therefore saving weight and space, and providing versatility
2、Flip the gear to easily change the gear deck height by 3mm, very practical
3、This hole diameter allows you to use shafts and tubes up to 32mm in diameter, such as for goTUBE and aluminum tube with an outer diameter of 14mm
4、These gears have a 14mm mounting style, so compatible with any 1302 or 1305 series clamping hub
5、You can create a 3:1 reduction or overspeed setting according to your application when using the pinion. When used in conjunction with a 30‑tooth servo gear, this combination produces a 3:1 underspeed, which reduces the final speed while increasing the torsion by 3 times

Package List

1 x Spur Gear
