Product Overview
Item Type: Surge Protective Device
Model: LTFL-24
Rated Working Voltage Un: 24V DC
Maximum Continuous Working Voltage Uc: 30V DC
Nominal Discharge Current In: 5kA (8/20us)
Maximum Throughput Imax: 10kA
Voltage Level Protection Up: ≤80V
Model: LTFL-24
Rated Working Voltage Un: 24V DC
Maximum Continuous Working Voltage Uc: 30V DC
Nominal Discharge Current In: 5kA (8/20us)
Maximum Throughput Imax: 10kA
Voltage Level Protection Up: ≤80V
Features
1、Surge Protector: Prevent the surge and overvoltage caused by lightning or travelling waves on the data line from harming related equipment.
2、Reliable Working: The nominal discharge current In is 5kA, and the maximum throughput Imax is 10kA, ensuring secure and reliable protection.
3、Practical Usages: Comes with large throughput, quick clamping time and ideal protection level to provide the circuit with timely protection.
4、Easy to Install: Can be installed in any standard switch box or power distribution box, and the installation can be conveniently completed.
5、Good Durability: Adopting premium materials and exquisite workmanship as well, the efficient voltage arrester is very durable for long use.
Package List
1 x Surge Protective Device
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 2.73 Inch |
| Height | 1.56 Inch |
| Length | 3.9 Inch |
