Product Overview
Item Type: T-Slot Aluminum Extrusion Profile
Material: Aluminum
Model: 3109-0024-0192
Length: Approx. 192mm / 7.6in
Width: Approx. 24mm / 0.9in
Size: Approx. 8mm / 0.3in
16mm / 0.6in
12mm / 0.5in
24mm / 0.9in
4mm / 0.2in
M4 x 0.7mm
Depth: Approx. 12mm / 0.5in
Diameter: Approx. 14mm / 0.6in
32mm / 1.3in
Material: Aluminum
Model: 3109-0024-0192
Length: Approx. 192mm / 7.6in
Width: Approx. 24mm / 0.9in
Size: Approx. 8mm / 0.3in
16mm / 0.6in
12mm / 0.5in
24mm / 0.9in
4mm / 0.2in
M4 x 0.7mm
Depth: Approx. 12mm / 0.5in
Diameter: Approx. 14mm / 0.6in
32mm / 1.3in
Features
1、Outer contour is square, the corner diameter is 32mm, which can be used with 32mm bearings
2、Chamfered edge of the slot provides a path for the V‑shaped wheel and the W‑shaped wheel, which can be used as a linear motion guide
3、Use this hole by sliding bearings with flanges on both ends to support the shaft, or just by inserting a 12mm square screw nut in the hole to generate linear motion
4、The extrusion profile is great framing materials for professional 3D printers and robots
5、Adopt good‑quality aluminum material, light weight with good strength and good corrosion resistance
Package List
1 x T-Slot Aluminum Extrusion Profile
Package Weight and Dimension
| Weight | 0.66 lb |
| Width | 1.17 Inch |
| Height | 1.17 Inch |
| Length | 7.8 Inch |
